Inclined Plane and Friction Board Manufacturer,Supplier and Exporter in Africa
Product Code : DA-FAM-11241
Quick Answer: The Inclined Plane and Friction Board is a hinged inclined plane on a wooden base, used to demonstrate the composition of a force and to find the coefficients of friction between different materials. The plane can be set at angles between 24 and 45 degrees approx.
Last updated: October 2026
Key Features
- Wooden base with hinged inclined plane and pulley
- Angle adjustable between 24 and 45 degrees approx.
- Supplied with a cylindrical metal roller
- Scale pan included
- Overall size 600 x 75 x 19 mm (L x W x H)
Technical Specifications
| Specification | Value |
|---|---|
| Dimensions (L x W x H) | 600 x 75 x 19 mm |
| Angle range | 24 to 45 degrees approx. |
| Base material | Wood |
About This Product
The hinged plane is raised to a chosen angle, and the pulley, metal roller and scale pan are then used to show how forces combine on a slope. The same arrangement serves to measure the coefficient of friction between different materials. At 600 mm long, the board sits comfortably on a standard bench.
Frequently Asked Questions
Q1. What angles can the inclined plane be set to?
The hinged plane can be set at angles between 24 and 45 degrees approximately.
Q2. What is supplied with the board?
A cylindrical metal roller and a scale pan are supplied. The board itself consists of a wooden base, a hinged inclined plane and a pulley.
Related: Forces and Motion range, Dynamics Track, Rod Mounting Pulley.
For a quotation on the Inclined Plane and Friction Board, contact Didactic Africa.
